PTFE Bellow Seals


PTFE Bellow Seals

Specifications

Material Teflon
Sealing faces Carbon, Silicon Carbide, Tungsten Carbide, Ceramic, GFT, CFT, SFT
Metal Part S.S 304 , SS 316, Hastelloy C, Alloy-20
Secondary Seal PTFE Bellow
Shaft Diameter 1/2
Pressure 10 bar
Temperature 20oC to +180oC

Buyers can lay their hands on our qualitative array of PTFE Bellow Seals that us designed and developed by keeping mind the market demands. We are noted Manufacturer, Exporter and Supplier of PTFE Bellow Seals in Maharashtra, India. We are backed by a team of qualifiers who take care the quality, thus optimum strength and long life span are assured.



More about PTFE Bellow Seals : Multi spring externally mounted, non pusher designed, suitable for handling extremely highly corrosive liquids. The contact parts of the fluid is PTFE and GFT composite bellows which are hydraulically balanced. All components which come in contact with the liquid being sealed are made of chemically inert material. The seal has no dynamic elastomers and hence, no fretting damage on the shaft. The rotary face is designed to replace and remove the worn out faces in a very short time and stationary part is designed with two side lapping, So if one lapping face damage , second side lapping can be used. Springs are PTFE coated to withstand corrosion attack from strong acids and hazardous environment.
