Sealless Magnetic Drive Pump


Sealless Magnetic Drive Pump

Specifications

Capacity Up to 25 m3/Hr
Head Up to 30 Meters
Temp Up to 20oC - +150oC
Applications Plating Plant, Anodizing, Metal Finishing Machines, Etching Machine,
Industries Application Where Leakage is Not Allowed

Our company is a preeminent Manufacturer, Supplier and Exporter of Sealless Magnetic Drive Pump. The Drive Pumps offered by us are lightweight, easy to operate and maintain. We maintain a large stock of the Pumps in our state-of-the-art warehouse in order to meet the bulk and urgent requirements of the buyers.

More about Sealless Magnetic Drive Pump : Leakless (India) Engineering Offer LMDP Series Seal less Magnetic Driven Pump is driven by a pair of magnet which are incorporated in the impeller and motor shaft respectively. The seal less pump structure eliminates shaft seals such as conventional mechanical seals, because the pump chamber is shielded the casing and the impeller is operated by magnet. The combine coupling torque of the drive magnet and impeller magnet drives sufficient driving power against the motor torque. The pump can avoid atmospheric hazardous effects due to the leakage problems. By eliminating the leakage and removing unreliable seals from the design, our seal less magnetic driven pumps provide immediate Cost, safety and reliability advantages over traditional sealed design.

Features And Advantages :

  • Highly Reliable, Compact Field Proven Reliability
  • Leakage-free, Sealless Structure
  • Easy Maintenance At Site
  • Light Weight, Easy to Handle
  • No Mechanical Seal, So No Leakage Problem


Material Of Construction :

  • Polypropylene (P.P)
  • Ultra High Molecular Weight (UHMW-PE)
  • Polyvinylidene Fluoride (PVDF)
  • Glass Filled Polypropylene (G.F.P.P)
  • Polytetrafluoroethylene (PTFE)
  • Cast Iron
  • Cast Steel (WCB)
  • CD4MCu
  • S.S 316 (CF8M)
  • S.S 304 (CF8)
  • S.S 316L (CF3M)
  • Hastelloy B (N12MV)
  • HastelloyOY C (CW12MW)
  • Alloy 20 (CN7M)
  • Duplex SS (Grade 4A,5A,6A)
  • Nickel (CZ-100)
  • Monel (M-35)
  • Carpentar 20 (CK-20)
  • Ni-hard
  • Bronze
  • Gun Metal
  • Hard Metal Casting
