Vertical Sealless And Glandless Pump


Vertical Sealless And Glandless Pump

Specifications

Type Vertical Glandless Pump
Capacity Up to 200 m3/Hr
Head Up to 150 Meters
Speed 1450 to 2850 RPM
Pump Size Pump Size
Temp Up to -20oC - +150oC

As a renowned Manufacturer, Exporter & Supplier from Maharashtra, India, we offer different types of Vertical Sealless And Glandless Pump for diverse applications. We make use of excellent quality raw materials for the fabrication of our durable Pump. Owing to its excellent functionality and longer operational life, our Vertical Sealless And Glandless Pump is widely in demand.

More about Vertical Sealless And Glandless Pump : Leakless (India) EngineeringOffer LVGP Series Vertical Sealless And Glandless Pumps Normal hydraulic terms do not differ from any conventional centrifugal pump. No mechanical seal or gland, so no breakdown of pump. The pump is designed in such a way that the liquid would normally try to pass through annular space , Where the impeller drive shaft enters the back plate (stuffing box).This liquid is diverted and returns as a controlled flow to the suction tank. The need for any seal is eliminated by allowing the leakage liquid to escape through the overflow connection to the overflow chamber. The liquid entering the suction flows around the impeller casing and leaves through the delivery under pressure. Between the annular gap of the upper rotor casing and impeller some leakage liquid escapes to the overflow chamber. The auxiliary impeller (Expeller) prevents the leakage liquid going further up and channelizes it through outlet in the overflow chamber. These pumps are ideally suited for continuous operation for clear liquid and slurries. This pump is at its best with negative suction. Compact design to save precious space. No seal or gland so 100% leak proof. No Coupling so no vibration and noise.

Material Of Construction :

  • Polypropylene (P.P)
  • Ultra High Molecular Weight (UHMW-PE)
  • Polyvinylidene Fluoride (PVDF)
  • Glass Filled Polypropylene (G.F.P.P)
  • Polytetrafluoroethylene (PTFE)
  • Cast Iron
  • Cast Steel (WCB)
  • CD4MCu
  • S.S 316 (CF8M)
  • S.S 304 (CF8)
  • S.S 316L (CF3M)
  • Hastelloy B (N12MV)
  • Hastelloy C (CW12MW)
  • Alloy 20 (CN7M)
  • Duplex SS (Grade 4A,5A,6A)
  • Phosphorus Bronze
  • Titanium
  • Ni-hard
  • Hard Metal Castings
  • Gun Metal


Applications And Industries Served :

  • Underground Tank Unloading
  • Acid Transfer
  • Sprinkle Systems
  • Filterpress Unit
  • Loading/unloading
  • Effluent Treatment Plant
  • Pickling Plant
  • Cooling Towers
  • Solvents Unloading
  • Water Treatment
  • Electro Plating
  • Scrubber Unit
